| • 節能-不洩漏壓縮空氣 • 排放口徑大，避免乳化液的形成 |
• Energy Saving – No compressed air will be leak • Big size of discharge pipe diameter, preventing emulsion |
| 型號 Model |
TEMCO-DV12 | TEMCO-DV13 | TEMCO-DV14 | TEMCO-DV16C |
| 最大空壓機流量 (m3/min) Max. Air Compressor Flow (m3/min) |
4 | 20 | 90 | 1000 |
| 最大冷乾機流量 (m3/min) Max. Dryer Flow (m3/min) |
8 | 40 | 180 | 2000 |
| 最大過濾器流量 (m3/min) Max. Filter Flow (m3/min) |
40 | 200 | 900 | - |
| 最小工作壓力 (bar) Min. Performance Pressure (bar) |
0.8 | 0.8 | 0.8 | 0.8 |
| 最大工作壓力 (bar) Max. Performance Presure (bar) |
16 | 16 | 16 | 16 |
| 重量 (kg) Weight (kg) |
0.8 | 2.0 | 2.9 | 5.9 |
| 入口 Entrance Region |
1 x G 1/2 | 2 x G 1/2 | 3 x G 3/4 | 2 x G 3/4 / 2 x G 1 |
| 出口 (管接頭口徑) Exit Region (Pipe Joint Diameter) |
1 x G 3/8 | 1 x G 1/2 | 1 x G 1/2 | 1 x G 1/2 |
| 出口 (連接軟管內徑) Exit Region (Hose Inner Diameter) |
10 - 13 mm | 13 mm | 13 mm | - |
